#ALP-016W House Plan

This luxurious one-story, classic Mediterranean-style waterfront house plan offers four bedrooms, two and one-half bathrooms, and a two-car garage. The beautiful French doors have arched transom accents adding detail and elegance to the entrance. The Contemporary layout of the open floor plan gives this home spacious appeal. There is a large kitchen with an eating bar opening to the family room. This design features optional elevations.

3 Sets	$750
5 Sets	$850
8 Sets	$1,000
Base Price (NOT for construction)	$650
CAD	$1,650
PDF	$1,150
Repro. Vellum	$1,150

Additional set for CAD	$500
Additional set for Printed plans (3 sets, 5 Sets, and 8 Sets)	$50
Additional set for Repro. Vellum and PDF	$150
Review Set (NOT for construction)	$150
Right Reading Reverse	$250

Ground (5-7 bus. days)	$30
Express (2-3 bus. days)	$45
Overnight	$60

Total Sqft.	1769
First Floor Sqft.	1769
Unheated Sqft.	463
Width	40
Depth	60
Levels	1
Bedrooms	4
Bathrooms	2
Half Bathrooms	1
Garage	2 Car Spaces
Garage Sqft.	403
Ext. Walls	Concrete Block
Ext. Material	Stucco
Ridge Height	16-10
Roof Material	Cement Tile Tile
Roof Pitch	5/12
Roof Loads	Roof: Live Load 30 Roof: Dead Load 25
Main Ceiling	11
Lower Ceiling	8
Master Bed Loc.	1
